3螺杆泵，适用于各种类型的流体，通常用作供应泵。
|
INSTALLATION DATA
|
|
|---|---|
|
Installation
|
Indoor or Outdoor
|
|
Environment
|
Industrial, Marine
|
|
Amb. Temperature Min/Max
|
-25°C (CS) and -40°C (LTCS) , storage only / 60°C * *
|
|
OPERATING CONDITIONS
|
|
|
Fluids
|
Mineral and synthetic lubricating oil; Hydraulic oil; Diathermic oil; DFD-U and HFDR phosphate organic esters; Glycols; Heavy and Light Fuels
|
|
Solid content
|
0% *
|
|
Viscosity range
|
between 1.2 and 5000 cSt * *
|
|
Speed
|
between 750 and 3600 rpm * *
|
|
Rotation (shaft view)
|
Clockwise
Counter clockwise on request |
|
TECHNICAL CHARACTERISTICS
|
|
|
Design available
|
STANDARD SEIM, ABS Type Approval,
BV MODE II, RINA alternative testing |
|
Flow rate
|
between 6 and 200 lpm
(between 0.36 and 12 m3/h; between 1.6 and 52.9 GPM) * * |
|
Suction pressure
|
between -0.5 and 10 barg (between -8 and 146 psi) *
|
|
Delivery pressure
|
16 barg (233 psi) MAX *
|
|
Operating temperature
|
between 0 and 150°C *
|
|
Seal
|
Mechanical
|
|
Bearing
|
Radial ball
|
|
Bearing lubrication
|
Self-lubricated
|
|
Drive
|
AC or DC motor
|
|
Construction shape
|
Horizontal or vertical
|
|
IN/OUT
|
Special versions
|
|
Safety valve
|
Internal recirculation
|
|
MATERIALS
|
|
|
Body/Flange
|
GGG40 *
|
|
Set of 3 screws
|
Nitrided carbon steel *
|
|
O-rings
|
Viton ®
|
|
Painting
|
On request
|
|
(*) For different values contact SEIM
|
|
