产品概述:带有定时齿轮的双螺杆泵,适用于各种不同类型的流体,也含有杂质,也可以完全由不锈钢制成,满足API676 IIED和IIIED的规定。
在线订购
产品详情 图片集锦

  带有定时齿轮的双螺杆泵,适用于各种不同类型的流体,也含有杂质,也可以完全由不锈钢制成,满足API676 IIED和IIIED的规定。


INSTALLATION DATA
Installation
Indoor or Outdoor
Environment
Industrial, Marine
Amb. Temperature Min/Max
-25°C (CS) and -40°C (LTCS) , storage only / 60°C *
OPERATING CONDITIONS
Fluids
Mineral and synthetic lubricating oil; Hydraulic oil; Diathermic oil; DFD-U and HFDR phosphate organic esters; Glycols; Heavy and Light Fuels; Asphalt and Bitumen; Food Industry; Cosmetics and detergents
Solid content
2 mm (3%) MAX *
Viscosity range
between 1 and 15000 cSt *
Speed
between 750 and 3600 rpm *
Rotation (shaft view)
Clockwise
Counter clockwise on request
TECHNICAL CHARACTERISTICS
Design available
STANDARD SEIM, API676 IIIED
, API676 IIED, BV Mode II, RINA
Flow rate
between 10 and 20000 lpm (between 0.6 and 1200 m3/h; between 2.7 and 5283.5 GPM) *
Suction pressure
10 barg (146 psi) MAX *
Delivery pressure
40 barg (581 psi) MAX *
Operating temperature
between 0 and 300 °C *
Seal
Single or Double Mechanical
Bearing
4 radial + 1 axial
Bearing lubrication
Based on the application
Drive
AC or DC motor, Steam turbine, diesel engine
Construction shape
Horizontal or vertical on feet IM1001 B3
IN/OUT
standard ANSI 150 B16.5 or DIN UNI EN 1092-1
Safety valve
It is ONLY possible to install a built-on safety valve with internal or external recirculation on request
MATERIALS
Body/Flange
Carbon steel or Stainless steel *
Set of 3 screws
Nitrided carbon steel or stainless steel *
Liner
Cast iron GG25; carbon steel; stainless steel
O-rings
standard Viton ®
Painting
standard SA2,5 + primer + final, total 160µ approximately; other painting cycles on request
(*) For different values contact SEIM
